SMD Embossed Carrier Tapes & Reels:

Integrated Packaging for Automated Electronics Assembly Designed for seamless integration into high - speed surface - mount technology (SMT) production lines, our SMD Embossed Carrier Tapes & Reels provide a complete solution for protecting, transporting, and feeding sensitive electronic components.

1. Unified Design for Precision and Efficiency - Carrier Tape Excellence:

- ESD & Moisture Protection:

Polyester (PET) or polypropylene (PP) tapes with ESD - dissipative coatings (10⁶–10¹¹ Ω/sq) and optional aluminum foil laminates to shield components from electrostatic discharge, humidity, and oxidation. - Precision Pockets: Uniformly embossed pockets (0402 to 2225 metric sizes) ensure secure fitment for resistors, capacitors, inductors, and ICs. Tight tolerances (±0.05mm) guarantee compatibility with pick - and - place machines.

- Reel Innovation: - Anti - Static Core & Flanges:

Constructed from conductive plastic to maintain ESD protection throughout the packaging system.

- Optimal Winding Tension: Engineered to prevent tape slippage or component shifting during transportation and automated feeding.

- Sprocket Hole Alignment: Standardized sprocket holes (4mm, 8mm, 12mm, 16mm pitch) ensure smooth indexing in SMT equipment.

2. Key Features for Streamlined Operations - Automation - Ready Performance:

- Flat, consistent tape profile reduces jamming in high - speed assembly lines. - Quick - release reel design allows rapid replacement without equipment downtime.

- Temperature & Chemical Resistance:

- Tapes withstand reflow soldering up to 260°C (short - term) and extended exposure to 125°C. - Reels resist solvents and disinfectants used in cleanroom environments.

- Component Security:

- Pressure - sensitive acrylic adhesive secures components during handling while enabling clean removal for repairs.

- Optional dust covers or resealable films add an extra layer of protection.

3. Compliance & Quality Assurance - Industry Standards:

- Meets EIA - 481 - C, IPC - 4901, and JEDEC J - STD - 033B for dimensional accuracy and moisture sensitivity. - Reels comply with ANSI/ESD S20.20 for electrostatic control. - RoHS & REACH Certified: - Free of hazardous substances, ensuring safety in medical, automotive, and aerospace applications. - ISO 9001 Manufacturing: - Rigorous quality checks at every stage guarantee defect - free performance.

4. Customization & Sustainability - Tailored Solutions:

- Tapes: Custom pocket depths, widths (8mm–56mm), and colors for non - standard components. - Reels: Sizes from 7” to 13” diameters with custom labeling (barcodes, logos, part numbers). - Eco - Friendly Options: - Recyclable materials and water - based adhesives minimize environmental impact.

5. Applications - Consumer Electronics:

Efficient feeding of SMDs in smartphones and wearables.

- Automotive: Protecting sensors and ECUs in harsh conditions.

- Medical Devices: Sterile packaging for implantable components.

- Aerospace: High - reliability packaging for avionics systems.

Choose our SMD Embossed Carrier Tapes & Reels to optimize your SMT workflow, reduce material waste, and enhance component integrity. Backed by advanced engineering and global compliance, our integrated solution is trusted by leading electronics manufacturers.

Contact us for a free sample or to discuss your custom packaging needs!
